Honor series mount 0201~40*40 tape reel packages, IC tray feeder mounter YT-202S
Machine main features
- Adopt High speed multi modular head, apply to ultra small chip 0201~40*40 mm large chip, wider component range;
- Brand new flight vision camera: Improve recognition performance, size up to 40*40 mm, apply to BGA or CSP etc;
- Vacuum sensing device: Each placement head with independent detection function, which improves the stability of the equipment and the reliability of the product;
- Optimum speed reach 80000 CPH;
- Combine high accuracy Mark recognition camera with fixed flight vision camera, ensure placement accuracy;
- Off-line programming, save time of changeover cycle;
- Software AI intelligent learning function and automatic optimization function.
- Two gantry, 10 spindles*2 Gantry, total 20 spindles;
- Flexible PCB handling capabilities, double rail, both gantry can mount the same large PCB at the same time, realizing flexible production.
Machine main parameter
| Model | YT-202S |
| PCB size | Max size: 500*450 mm(Single side) 500*300 mm(Double side) Min size: 50*50 mm |
| PCB thickness | 0.5-4.5 mm |
| Production management MES system | Customized (Option) |
| Off-line programming | Available |
| Camera | Head flight vision recognition component Vision alignment + Mark correction |
| Repeat precision | ±0.02 mm |
| Mounting height | ≦20 mm |
| Optimal speed | 80000 CPH |
| Component range | Min 0201~40*40 tape reel packages and IC tray feeder etc. |
| No.of heads | Double side: 20 pcs Single side:10 pcs |
| X,Y,Z, Axis drive way | High-end magnetic linear motor + Servo motor |
Market
Our products had exported to more than 30 countries and regions, including South Korea, India, Vietnam, Tunisia, Egypt,Turkey, Russia, Brazil etc. And here are some of our big customers:
SURYA, POLYCAB, FIEM, RK, GK, TECHNO LED, CALCOM, ACK , KENDAL, RangDong, UNISTAR, and so on.
Our Exhibitions
Eton has participated in many exhibitions of foreign countries , such as India Mumbai Exhibition, India Delhi Exhibition, Egypt Exhibition, Turkey Exhibition, Pakistan Exhibition, etc and trading with more than 20 countries. Furthermore, we have took part in our domestic large exhibition, like Guangzhou Guangya Exhibition, Shanghai Munich Exhibition, Chongqing LED light Exhibition, etc.
Packages
Our package step is follow the blowing:
Step 1: Packing in film package to prevent dust and water to the machine
Step 2: Packing in foam cotton to protect the outside of the machine
Step 3: Packing in vacuum package to keep dry of the machine during transportation
Step 4: Transportation by truck to specified port
Service
- We provide whole line solution for our clients needs.
- We have some official site in India as Mumbai and New Delhi, also have site in Egypt, Turkey that can provide service timely with our engineers.
- As long as you buy our machine we will arrange our engineers to install debug and training for you for free, until you learned how to operate the machine.
- Chinese engineer can provide online services especially in the period of the COVID-19 epidemic.
- If necessary, Chinese engineers will come to your factory for free install and training you how to operate the machine.
- Free up-date of the machine.
- We will arrange our engineers to visit your factory for check or test the status of the machine.
- If you have any problem you can contact us with any time we have 24 hours service for solving your problem on time.
FAQ
Q. What is your merits of the machine to others production?
A. Initially, we have a strong R&D department for studying our productions, and our clients can enjoy free up-grade of the machine to get latest information about technology and equipment, besides, we have a 52000 square meters industrial park to serve the production, assembly, and commissioning of our machines.
Q. Does your machines have quality certificates?
A. We are high-tech enterprise with CE, SIRA, CCC , ISO awarded as "Well-know brand" and many technology patents, and have rich experience (more than 11 years) in LED light production line program.
Q. Can I go and see if you have sold the equipment to India?
A. Yes, we have sold our machine in India, but for the fact we can't decide it for my customer, but I will try to contact my customer. Hope you can understand, because no one wants their competitors to visit their manufacturing site.
Q. What is your actual speed of your products?
A. For the actual speed of the machine which is constrained by many factors, that related to the number of the components, the time to send PCB board and receive the board that will have influence on the speed when in production, and is decide for the actual products and needs.
